| Mechanical Performance | |
|---|---|
| Weight | 7.9lbs/3.6kg（included handle bar and the battery） |
| Maximum Payload | 22lbs/10kg |
| Gimbal Dimensions |
With Extension Arm:570mm(W)*395mm(D)*480mm(H) Without Extension Arm:570mm(W)*300mm(D)*480mm(H) |
| Supported Cameras | |
|---|---|
| Sony |
· Sony F55 · Sony FS5 · Sony FS7 · Sony FS100 · Sony FS700 |
| Canon |
·Canon EOS 1D ·Canon C100 ·Canon C300 ·Canon C500 ·Canon T5i |
| RED |
·RED Raven ·RED Epic ·RED Dragon ·RED Scarlet ·RED Weapon |
| ARRI |
·ARRI Alexa Mini ·ARRI Alexa M |
| Blackmagic |
·Blackmagic Cinema Camera ·Blackmagic URSA Mini |
| Camera Tray Dimensions |
With Extension Arm:265mm*228mm*177mm Without Extension Arm:265.8mm*183mm*177mm |
| Working Performance | |
|---|---|
| Angular Vibration Range | 0.02° |
| Mechanical Endpoint Range |
Yaw Axis: ±360° continuously Tilt Axis: Up 135° to Down 175° Roll Axis: Left 75° to Right 235° |
| Static Current | 200mA |
| Dynamic Current | 200mA |
| Lock Rotor Current | 10000mA |
| Expansion Port | |
|---|---|
| Bluetooth | BLUETOOTH 4.0 |
| Bluetooth Control Range | 5m |
| Control Interface | 2.4G |
| 2.4G Remote Control Range | 50m |
| USB Connection |
Input: Micro USB Output: Mini 10PIN |
| PPM | Generic PPM Protocol |
| CAN | Generic CAN Protocol |
| Power Output Port | Mini USB 5V 1A 5PIN |
| DC OUT | 3.5mm 14.8V 0.8A |
| Battery | |
|---|---|
| Capacity | 2800mAh |
| Battery Life | 4~8 hrs |
| Working Voltage | 14. 8V |
| Working Temperature | 0~50℃ |
| Charger Output Voltage | 16.8V |
| Wireless Thumb Controller (Optional) | |
|---|---|
| Weight | 100g |
| Battery Capacity | 600mAh |
| Battery Voltage | 3.7V |
| Working Current | 50mA |
| Locked Current | 10mA |
| Standby Time | 24h |
| Wireless Type | 2.4G |
| Valid Range | 50m |
| Charging Voltage | 5V |
| Sufficently Charging Time | 2 hours |
| Start/Stop recording Control | supported cameras: Canon 5DII/5DIII/6D/60D/7D/70D, Sony a7S/a7SII/a7R/a7RII, Panasonic GH4/GH3, BMPCC/BMCC/BMPC |
| Focus Control | supported cameras and lens: Canon 5DII/5DIII/6D/60D/7D/70D(Will support more cameras and lens with firmware ) |
| Aperture Control | (will be available with firmware ) |
